Pressure Control Valves VBSO-06T
- Home
- Products
- Cartridge Valves
- Pressure Control
- Pressure Control Valves
- Specifications
- How to Order
| Model Number | Maximum Pressure (bar) | Pliot Ratlo | Adjustment Pressure (bar) | Maximum Flow (lpm) | Weight (kg) |
|---|---|---|---|---|---|
| VBSO-06T | 350 (5076 psi) | 3.2:1 / 8:1 | 100~350 | 140 (36.98 gpm) | 1.40 (3.09 lbs) |
| Fluid Type | ISO VG 32, 46, 68 | ||||
| Viscosity (cSt) | 10~400 (59~1854 SSU) | ||||
| Operating Temperature (°C) | -30~100 (-22~212°F) | ||||
| Contamination Level | ISO4406. 20/18/15 NAS1638. 9 | ||||
