COD Series Coil COD10
- Home
- Products
- Hydraulic Accessories
- Hydraulic Valve Accessories
- COD Series Coil
- Specifications
- How to Order
| Model Number | VOLTAGE (V) | HOLDING CURRENT (A) | Weight (kg) | ||
|---|---|---|---|---|---|
| SOURCE RATED | HZ | RANGE | |||
| COD10-A1-＊ | RAC110V | 50 | 100~120 | 0.19 | 0.34 (0.75lbs) |
| 60 | |||||
| COD10-A2 -＊ | RAC220V | 50 | 200~240 | 0.1 | |
| 60 | |||||
| COD10-D1 -＊ | DC12V | 10.9~13.2 | 1.7 | ||
| COD10-D2 -＊ | DC24V | 21.8~26.4 | 0.9 | ||
- Above value based on temperature 30℃, electric voltage allowance 10%.
- Coil-COD08 series application for VWE-10 series.
