| Model Number | Maximum Pressure | Pllot Ratio | Adjustment Pressure | Maximum Flow | Weight |
|---|---|---|---|---|---|
| VCQ-08M | 350 (5076 psi) | 4:1 | *~350 | 30 (7.93 gpm) | 0.19 (0.42 lbs) |
| Fluid Type | ISO VG 32, 46, 68 | ||||
| Viscosity | 10~400 (59~1854 SSU) | ||||
| Operating Temperature | -15~70 (-5~158oF) | ||||
| Contamination Level | ISO4406. 21/19/16 NAS1638,10 | ||||
