TL4 Series TL4-39-H
- Home
- Products
- Hydraulic Accessories
- Oil Cooler
- TL4 Series
- Specifications
- How to Order
| Flow (L/min) |
Maximum Antipyretic (Lcal/hr) |
Pressure (kg/cm2) |
Voltage (V,±10%) |
Phase | Frequency (Hz) |
Current (A) |
Capacity (Watt) |
Speed (RPM) |
Air (m3/hr) |
Protection (IP) |
Noise Value (dB(A)) |
Fan Certifcation | Weight (Kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 200 | 26000 | 20 | DC24 | - | - | 4.1 | 49.2 | 2313 | 2658 | 54 | 74.5 | CE | 15.9 |
- When the cooler is applied with hydraulic system, in order not to be broken by surge in the system. Suggest installing the oil reducing device.
- Best how-to-use: using another pump to draw the oil in the fuel tank into the cooler cooled. Make it an individual recycled circuit.
- If the data sheets above changed, based on actual products.
- If you have any special inquiry of this product, please feel free to contact with us.
