Features
- A solenoid operated two-port, pressure-compensated, spool-type, proportional flow control valve.
- The valve will regulate flow out of port 2 regardless of system working pressure . With an increasing current applied to the solenoid , the normally close will increase output flow, the normally open will decrease output flow.
- Specifications
- How to Order
| Model Number | Operating Pressure (bar) | Maximum Flow (lpm) | Maximum Current (mA) | Voltage (VDC) | Weight (kg) |
|---|---|---|---|---|---|
| EVOF-13A | 350 (5076 psi) | 34 (8.98 gpm) | 1300±10% | 12 | 0.73 (1.61 lbs) |
| 650±10% | 24 | ||||
| Fluid Type | ISO VG 32, 46, 68 | ||||
| Viscosity (cSt) | 10~400 (59~1854 SSU) | ||||
| Operating Temperature (°C) | -30~100 (-22~212 °F) | ||||
| Contamination Level | ISO4406. 20/18/15 NAS1638. 9 | ||||
