Proportional Directional Valves (Non Compensated Flow Regulators) EVEP-08
- Home
- Products
- Cartridge Valves
- Proportional
- Proportional Directional Valves (Non Compensated Flow Regulators)
- Specifications
- How to Order
| Model Number | Maximum Pressure (bar) | Maximum Flow (lpm) | Rated Current (mA) | Voltage (VDC) | Weight (kg) |
|---|---|---|---|---|---|
| EVEP-08 | 210 (3046 psi) | 10 (2.64 gpm) | 1000±10% | 12 | 0.64 (1.41 lbs) |
| 500±10% | 24 | ||||
| Fluid Type | ISO VG 32, 46, 68 | ||||
| Viscosity (cSt) | 10~400 (59~1854 SSU) | ||||
| Operating Temperature (°C) | -30~100 (-22~212°F) | ||||
| Contamination Level | ISO4406. 20/18/15 NAS1638. 9 | ||||
