Directional Valves VEPD-10

Features

  • A cartridge-style, pilot-operated, hydraulic directional valve for two-way circuits requiring remote pilot actuation.
  • When unpiloted, blocks flow from 3 to 2. On remote pilot signal at 1, the valve shifts to open from 2 to 3, bidirectionally.

Inquiry
PDF
  • Specifications
  • How to Order
Model Number Maximum Pressure (bar) Maximum Flow (lpm) Weight (kg)
VEPD-10 350 (5076 psi) 40 (10.57 gpm) 0.16 (0.35 Ibs)
Fluid Type ISO VG 32, 46, 68
Viscosity (cSt) 10~400 (59~1854 SSU)
Operating Temperature (°C) -30~100 (-22~212°F)
Contamination Level ISO4406. 20/18/15 NAS1638. 9
